LDK 650W-670W Solar Panel
LDK 650W-670W Solar Panel
Highly Cost-effective LDK Brand 650W-670W Bifacial A Grade Monocrystalline Solar Panel
- Model Number: LDK-650-670W
- Cell Size: 210x105mm
- Panel Dimensions: 2384*1303*35/mm
- Panel Efficiency: 21%
- Certificate: CE/TUV/ETL
- Warranty: 25 years
- Frame: Anodized aluminium alloy
- Solar Cell: Mono 210x105mm
- Frame Color: Color Silvery, Black
- OEM: Acceptable
- Product name: Polycrystalline Solar Panles
- Weight: 34.5kg
- Name: Solar Power Panel
Key product features and benefits
- Antireflective glass
- Translucency of normal luminance is increased by 2%
- Module efficiency is increased by 2%
- Self-cleaning function
- Service life is as long as 25 years (30 years optional)
- High Efficiency PV Cells
- Appearance Consistency
- Color sorting ensure consistent appearance on each module
- Anti-PID
- IP67 protection level
- Heat dissipation
- Long service life
What can Dawnice do?
- High Quality Products
- DDP Service
- Friendly and Professional Customer Service
- Solar system solution design
- Solar inverter, lithium battery storage system also are available.
- Multiple payment supported(T/T, Paypal, XTransfer, L/C, Western Union, D/P etc. )
|
Product number
|
650 | 655 | 660 | 665 | 670 |
|
quality assurance
|
|||||
|
product quality assurance
|
12 years | ||||
|
Power output guaranteed
|
12-year 91.5% output power guarantee, 25-year 84.3% output power guarantee | ||||
|
Electrical performance parameters (STC)
|
|||||
|
Peak power (Pmax)
|
650 Wp | 655 Wp | 660 Wp | 665 Wp | 670 Wp |
|
Peak working voltage (Vmpp)
|
37.39 V | 37.59 V | 37.79 V | 37.99 V | 38.19 V |
|
Peak operating current (Impp)
|
17.39 A | 17.43 A | 17.47 A | 17.51 A | 17.55 A |
|
Open circuit voltage (Voc)
|
45.29 V | 45.49 V | 45.69 V | 45.89 V | 46.09 V |
|
Short circuit current (Isc)
|
18.43 A | 18.49 A | 18.52 A | 18.58 A | 18.63 A |
|
Component efficiency
|
20.92% | 21.09% | 21.25% | 21.41% | 21.57% |
|
Power deviation (positive)
|
3% | 3% | 3% | 3% | 3% |
| Standard test conditions (STC): solar radiation flux 1000W/m2, atmospheric parameter 1.5, module temperature 25℃.. | |||||
|
Electrical performance parameters (NOCT)
|
|||||
|
Peak power (Pmax)
|
492 Wp | 496 Wp | 500 Wp | 504 Wp | 508 Wp |
|
Peak working voltage (Vmpp)
|
34.89 V | 35.09 V | 35.29 V | 35.49 V | 35.69 V |
|
Peak operating current (Impp)
|
14.11 A | 14.14 A | 14.17 A | 14.21 A | 14.24 A |
|
Open circuit voltage (Voc)
|
42.59 V | 42.79 V | 42.99 V | 43.19 V | 43.39 V |
|
maximum endurance temperature
|
42±3 °C | ||||
| Cell nominal operating temperature (NOCT): solar radiation flux 800W/m2, atmospheric parameter 1.5, ambient temperature 20°C, wind speed 1 m/s. | |||||
|
temperature characteristics
|
||
|
Operating temperature
|
-40~85 °C | |
|
Temperature coefficient (Pmax)
|
-0.32 %/°C | |
|
Temperature Coefficient (Voc)
|
-0.26 %/°C | |
|
Temperature Coefficient (Isc)
|
0.054 %/°C | |
|
System Integration Parameters
|
||
|
Maximum system voltage
|
1500 V | |
|
Fuse rated current
|
25 A | |
|
physical parameters
|
||
|
Component size (height/width/thickness)
|
2384x1303x35 mm | |
|
weight
|
34.5 kg | |
|
Cell type
|
Monocrystalline silicon | |
|
Number of cells
|
132 | |
|
border type
|
Anodized aluminum alloy | |
|
Junction box protection class
|
IP 68 | |
|
Cable cross section
|
4 mm2 | |
|
cable length
|
350 mm | |
