48V 200Ah 10KW Stackable Lifepo4 Lithium Batteries
48V 200Ah 10KW Stackable Lifepo4 Lithium Batteries
On sale
0
0
0
0
Days
0
0
Hrs
0
0
Min
0
0
Sec
Dawnice 48V 200Ah Stackable Lithium Ion Batteries 10KW Ground Eco 10KWH Stacked Lifepo4 akku ESS Energy Storage Battery System
- Product Name: Stackable LiFePo4 Lithium Batteries; Lithium Battery Pack; LiFePo4 Battery Pack;
Model Number: DW-ST30-LV
- Warranty: 5 years
- Anode Material: LFP
- Rechargeable: Yes
- Application: Solar System ,Power Back Up ，UPS system
- Place of Origin: China
- ODM & OEM: Supported
- Certification: MSDS, UN38.3, CE, IEC62619 (Cell)
- Life Cycling(0.5C&25℃): 6000 cycles @ 0.5C；80%DOD
Key product features and benefits
- Modular Design: Light weight, small size
- Larger Capacity & Higher Supporting Power: 25KWh to 100KWh
- High Quality: A Grade lithium battery cell
- Widely Application: Off-Grid / Hybrid Solar Storage System; Industry Project etc.
- BMS with RS485/CAN:100% Protection, high compatibility, available for most inverters
- Long Service Lifespan: Up to 6000 cycles @ 0.5C；80%DOD
The Dawnice DW-48V 200Ah 10KW, a Lithium Iron Phosphate Battery, provides cutting-edge technology that is both the safest and most durable lithium chemistry. With the ability to reach over 5000 cycles, the DW-48V 200Ah 10KW can be recharged numerous times while delivering a 100% depth of discharge. This battery is ideal for various applications such as solar, Telecom, Wind, Marine RV and deep cycle applications. Furthermore, it can handle more than 200 amps of continuous charge or discharge and up to 2000 amps for starting / peak energy.
What can Dawnice do?
- High Quality Products
- DDP Service
- Friendly and Professional Customer Service
- Solar system solution design
- Solar inverter, lithium battery storage system also are available.
- Multiple payment supported(T/T, Paypal, XTransfer, L/C, Western Union, D/P etc. )
| 5-25KWH Ground Eco HV Battery Energy Storage System | |||||||||
| Model Capacity | DW-Elebox5 -HV | DW-Elebox7 -HV | DW-Elebox10 -HV | DW-Elebox12 -HV | DW-Elebox15 -HV | DW-Elebox17 -HV | DW-Elebox20 -HV | DW-Elebox23 -HV | DW-Elebox25 -HV |
| System Demo |  |
||||||||
| Battery Module | ELEBOX-HV—2.56 (2.56kWh, 51.2V, 36.3kg,593/355/146.5) | ||||||||
| Number Of Modules | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| Energy Capability | 5.12kWh | 7.68kWh | 10.24kWh | 12.8kWh | 15.36kWh | 17.92kWh | 20.48kWh | 23.04kWh | 25.6kWh |
| Nominal Voltage | 102.4V | 153.6V | 204.8V | 256V | 307.2V | 358.4V | 409.6V | 460.8V | 512V |
| Operation Voltage Range | 94.4-113.6V | 141.6-170.4V | 188.8-227.2V | 236-284V | 283.2-340.8V | 330.4-397.6V | 377.6-454.4V | 424.8-511.2V | 472-568V |
| Dimension mm (H/W/D) | 424/593/355 | 570.5/593/355 | 717/593/355 | 863.5/593/355 | 1010/593/3551 | 1157/593/355 | 1303/593/355 | 1450/593/355 | 1596/593/355 |
| Weight | 105.5kgs | 141.5kgs | 177.5kgs | 213.5kgs | 249.5kgs | 285.5kgs | 321.5kgs | 357.5kgs | 393.5kgs |
| Battery Type | Cobalt free Lithium Iron Phosphate (LFP) | ||||||||
| Standard Charge/ Discharge Current | 25A@0.5C | ||||||||
| IP Protection | IP 65 | ||||||||
| Installation | Wall-mounted or Floor Installation | ||||||||
| Operation Temperature Feature | 0 ℃to 45℃ | ||||||||
| DOD | 80% | ||||||||
| Cycle Life | 6000 cycles @ 0.5C；80%DOD | ||||||||
| Warranty (0.5C&25℃) | 5/10 Years | ||||||||
| Communication Port | CAN/RS485 | ||||||||
| Certification | CE, IEC62619(Cell&Pack),MSDS,ROHS,UN38.3 | ||||||||
| 30-100KWH Ground Eco LV Battery Energy Storage System | ||||||||
| Model Capacity | DW-Elebox30 -LV | DW-Elebox40 -LV | DW-Elebox50 -LV | DW-Elebox60 -LV | DW-Elebox70 -LV | DW-Elebox80 -LV | DW-Elebox90 -LV | DW-Elebox100 -LV |
| System Demo | |
|||||||
| Battery Module | ELEBOX-LV—10 (10.24kWh, 200AH,51.2V,96kg,736*455*258) | |||||||
| Battery Type | LiFePo4 | |||||||
| Number Of Modules | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| Energy Capacity （kW·h） | 30.72 | 40.96 | 51.2 | 61.44 | 71.68 | 81.92 | 92.16 | 102.4 |
| Useable Capacity（kW·h） | 27.6 | 36.9 | 46.1 | 55.3 | 64.5 | 73.7 | 82.9 | 92.2 |
| Normal Voltage(V) | 51.2 | |||||||
| Operating Voltage Range(V) | 44.8~56 | |||||||
| Standard Charge/ Discharge Current | 300A@0.5C | 400A@0.5C | 500A@0.5C | 600A@0.5C | 700A@0.5C | 800A@0.5C | 900A@0.5C | 1000A@0.5C |
| Dimension mm (W/D/H) | 736*455*880 | 736*455*1140 | 736*455*1395 | 736*455*1653 | 736*455*1911 | 736*455*2170 | 736*455*2430 | 736*455*2685 |
| Weight（KG） | 96*3 | 96*4 | 96*5 | 96*6 | 96*7 | 96*8 | 96*9 | 96*10 |
|
General
|
||||
|
Operation Temperature
|
0 ℃to 45℃ | |||
|
IP Protection
|
IP 60 | |||
|
Installation
|
Floor installation | |||
|
Warranty
|
5 years | |||
|
BMS Monitoring Parameters
|
SOC,System voltage,current ,cell voltage | |||
|
Communication Port
|
CAN | |||
|
Application
|
||||
|
Application scenarios
|
Solar System ,Power Back Up ，UPS system | |||
|
Life Cycling (0.5C &25℃)
|
6000 cycles @ 0.5C；80%DOD | |||
|
Communication Port
|
CAN/RS485 | |||
