Key product features and benefits
What can Dawnice do?
|
Product number
|
580 | 585 | 590 | 595 | 600 |
|
quality assurance
|
|||||
|
product quality assurance
|
12 years | ||||
|
Power output guaranteed
|
12-year 91.5% output power guarantee, 25-year 84.3% output power guarantee | ||||
|
Electrical performance parameters (STC)
|
|||||
|
Peak power (Pmax)
|
580 Wp | 585 Wp | 590 Wp/td> | 595 Wp | 600 Wp |
|
Peak working voltage (Vmpp)
|
33.94 V | 34.12 V | 34.32 V | 34.5 V | 34.7 V |
|
Peak operating current (Impp)
|
17.1 A | 17.15 A | 17.2 A | 17.25 A | 17.3 A |
|
Open circuit voltage (Voc)
|
40.8 V | 41 V | 41.2 V | 41.4 V | 41.6 V |
|
Short circuit current (Isc)
|
18.11 A | 18.16 A | 18.21 A | 18.26 A | 18.32 A |
|
Component efficiency
|
20.49% | 20.67% | 20.85% | 21.02% | 21.2% |
|
Power deviation (positive)
|
3% | 3% | 3% | 3% | 3% |
| Standard test conditions (STC): solar radiation flux 1000W/m2, atmospheric parameter 1.5, module temperature 25℃. | |||||
|
Electrical performance parameters (NOCT)
|
|||||
|
Peak power (Pmax)
|
439 Wp | 443 Wp | 447 Wp | 450 Wp | 454 Wp |
|
Peak working voltage (Vmpp)
|
31.47 V | 31.67 V | 31.84 V | 31.96 V | 32.15 V |
|
Peak operating current (Impp)
|
13.95 A | 13.99 A | 14.04 A | 14.08 A | 14.12 A |
|
Open circuit voltage (Voc)
|
37.94 V | 38.13 V | 38.32 V | 138.5 V | 38.69 V |
|
Short circuit current (Isc)
|
14.085 A | 14.89 A | 14.93 A | 14.97 A | 15.02 A |
|
maximum endurance temperature
|
42±3 °C | ||||
| Cell nominal operating temperature (NOCT): solar radiation flux 800W/m2, atmospheric parameter 1.5, ambient temperature 20°C, wind speed 1 m/s. | |||||
|
temperature characteristics
|
||
|
Operating temperature
|
-40~85 °C | |
|
Temperature coefficient (Pmax)
|
-0.32 %/°C | |
|
Temperature Coefficient (Voc)
|
-0.26 %/°C | |
|
Temperature Coefficient (Isc)
|
0.054 %/°C | |
|
System Integration Parameters
|
||
|
Maximum system voltage
|
1500 V | |
|
Fuse rated current
|
25 A | |
|
physical parameters
|
||
|
Component size (height/width/thickness)
|
2172x1303x35 mm | |
|
weight
|
30 kg | |
|
Cell type
|
Monocrystalline silicon | |
|
Number of cells
|
120 | |
|
border type
|
Anodized aluminum alloy | |
|
Junction box protection class
|
IP 68 | |
|
Cable cross section
|
4 mm2 | |
|
cable length
|
350 mm | |
